Electric Hydraulic Jack - DSJA380/380-1

Product Item : DSJA380/380-1
Multi-functional jack(3 in l:Lifting + lnflating +Light)
Product description：♦1. Combine two functions of jack and Tyre Inflator Pump in one machine ♦2. Adopt self-developed small flow and large efficiency gear pump,reduce electrical power.reduce the work of car batteries and
Inquiry

Product Name	Multi-functional jack(3 in l:Lifting + lnflating +Light)
Model No.	DSJA380	DSJA380-1
Lifting Function Specification
Rated Power	150W	150W
Operating Voltage	DC 12V	DC 12V
Max.Current	13A	13A
Fuse	15A	15A
Max.Loading Car Weight	3T/5T	3T/5T
Min.Height	115/135/155mm	135/155mm
Max.Height	310/360/450mm	360/450mm
Inflating Function Specification
Max Pressure	150PSI	150PSI
Air Flow	35L/min	35L/min
Current	10A	10A
Air hose length	0.65m	0.65m
Power Cable	3.5m	3.5m
Package	Color box with foam(Plastic tool box)
N.W./G.W.	4.4/4.9kgs(4.4/6.2kgs)	4.7/5.2kgs(4.7/6.5kgs)
Master Carton Size	380345405mm(565395305mm)
Set/ctn	4pcs(3pcs)
20FT	2108pcs(1233pcs)
