| MIG-200LG/1 | MIG-200LG/2 | MIG-200LG/3 | |||
| Power voltage(V) | 220V±10% | 220V/400V±10% | 400V±10% | ||
| Rated input capacity(KVA) | 7.5 | 7.5 | 7.5 | ||
| No-load voltage(V) | 54 | 54 | 54 | ||
| Output current range MIG (A) | 20-200 | 20-200 | 20-200 | ||
| Output current range MMA (A) | 20-180 | 20-180 | 20-180 | ||
| Usable wire (mm) | 0.6-1.0 | 0.6-1.0 | 0.6-1.0 | ||
| Usable electrode (mm) | 1.6-4.0 | 1.6-4.0 | 1.6-4.0 | ||
| Duty cycle(%) | 60 | 60 | 60 | ||
| Efficiency | 85% | 85% | 85% | ||
| Protection degree | IP21S | IP21S | IP21S | ||
| Insulation degree | F | F | F | ||
| Weight(kg) | 26.0 | 26.0 | 26.0 | ||
| Dimensions(mm) | 720x280x440 | 720x280x440 | 720x280x440 | ||
| INPUT OPTIONAL 220V, 220/400V, 400V | ||
| INVERTER IGBT TECHNOLOGY | ||
| DIGITAL DISPLAY | ||
| THERMAL PROTECTION | ||
| MIG/MMA | ||
| MOUNT MAX 15 KG WIRE | ||
| GAS/NO GAS |
