| FEATURES : | ||||||
| INPUT 220V OR 110/220V | ||||||
| INVERTER IGBT TECHNOLOGY | ||||||
| DIGITAL DISPLAY | ||||||
| THERMAL PROTECTION ,ARC FORCE , ANTI-STICK , HOT START , SHORT CIRCUIT PROTECTION , VRD(OPTIONAL) | ||||||
| SMOOTH AND STABLE ARC ,EXCELLENT WELDING PERFORMANCE. | ||||||
| ITEM/MODEL | MMA-160E | MMA-180E | MMA-200E | |
| Power voltage(V) | 220±10% | 220±10% | 220±10% | |
| Rated input capacity(KVA) | 6.0 | 7.0 | 8.0 | |
| No-load voltage(V) | 65 | 65 | 65 | |
| Output current range(A) | 20-160 | 20-180 | 20-200 | |
| Usable electrode (mm) | 1.6-4.0 | 1.6-5.0 | 1.6-5.0 | |
| Duty cycle(%) | 60 | 60 | 60 | |
| Protection degree | IP21S | IP21S | IP21S | |
| Insulation degree | F | F | F | |
| Efficiency | 85% | 85% | 85% | |
| Power factor | 0.93 | 0.93 | 0.93 | |
| Weight(Kg) | 5.5 | 5.5 | 5.5 | |
| Dimensions(mm) | 350X135X280 | 350X135X280 | 350X130X260 | |
| Dimensions(mm) | 350X130X260 | 350X130X260 | 350X130X260 | |
