| MIG-280PAL | |
| Power voltage(V) | 380V±10% |
| Rated input capacity(KVA) | 8.6 |
| No-load voltage(V) | 56 |
| Output current range MIG (A) | 50-280 |
| Output current range MMA (A) | 20-220 |
| Usable wire (mm) | 0.6-1.2 |
| Usable electrode (mm) | 1.6-4.0 |
| Duty cycle(%) | 60 |
| Efficiency | 85% |
| Protection degree | IP21S |
| Insulation degree | F |
| Weight(kg) | 25 |
| Dimensions(mm) | 945x396x762 |
| INPUT 380V-50/60Hz | |
| INVERTER IGBT TECHNOLOGY | |
| DIGITAL DISPLAY | |
| MCU CONTROL SYSTEM | |
| PULSE | |
| 2T/4T TORCH SWITCH LATCHING | |
| AUTOMATIC BURN BACK | |
| HIGH DUTY | |
| MOUNT MAX 15 KG WIRE | |
